QUICK START

Count up and Count down share many of the same features apart from the obvious.

The control surface have blue arrows above/below each number (HH:MM:SS) where you can increase/decrease with 1, it is also possible to hold these buttons for faster increments.

The green play button to start the timer, the orange pause button for pause and the red reset button for reset.

The reset button has two functions: Single click will stop the timer, and reset the value to what was prior to start, the 2nd click will set timer back to its default value, which can be changed in Settings->Defaults.

The count down also has a field to show if timer is currently in overtime.

The digits colors will reflect the current state.

Normal - White.

Warning - Orange.

Alert/Overtime - Red.

The default values for Warning/Alert can be changed in Settings->Defaults.

Bottom left you'll find the repeat timer function, when this is enabled clock will reset and start over when time hits 00:00:00.

By hitting MM button, MM will increase with 10

By hitting SS button, SS will go to 00

To exit the menu press the top right corner's menu-button.

Displays the current time of day.

The time can be adjusted in Settings->Time

Adjust the brightness of the control surface.

There is possiblity of burnins on higher brightness settings, We recommend 20% brightness.

The device has a dedicated RTC to keep time when the device if off. Here you can adjust the current time.

Default time: Count up

Set the default time for counting up.

Note: you may need to reset the clock in Count Up menu for changes to take effect, This is because if you already have entered the menu and or changed the value in this session, the value has been stored.

Default time: Count down

Set the default time for counting down

Note: you may need to reset the clock in Count Up menu for changes to take effect, This is because if you already have entered the menu and or changed the value in this session, the value has been stored.

Default time: Warning

Set the default time when timer should change color to yellow. To indicate that time is running out.

Default time: Alert

Set the default time when timer should change color to red. To indicate that even less time is remaining.

Toggle switch: Flash

With this setting on, timer will slowly flash when timer meets Warning or Alert state.

This is not visually represented on the control surface display.

Toggle switch: Allow overtime

With this setting on, the timer is allowed to pass 00:00:00 and go into negative values. a - is added and the clock keeps ticking.

To change style of overtime, please see Settings->Position/Style

Font Size:

Choose a fontsize with relative size 1 - small to 10 - large.

The fontsize is scaled relative to the screen resolution.

HH:MM:SS:

Enable disable the visibility of Hour, Minute and Seconds

Color Wheel: ​

Background:
Use the RGB arrows to change background color of the output

Font Color:

Select either HH:MM:SS, Warn og Alert to change color associated with the different mode.

Output Style (overtime):

Change the output style of the counter.

Here you can set the overtime indication to be centered around the clock, perfect for PiP, or fullscreen, it's also possible to disable either the red box or the overtime text.

Auto

Auto-detect from EDID.

Value|||Resolution|||Frequency|||Notes

1|||VGA (640x480)||||||

2|||480p|||60Hz|||

3|||480p|||60Hz|||16:9 apsect ratio

4|||720p|||60Hz|||

5|||1080i|||60Hz|||

6|||480i|||60Hz|||

7|||480i|||60Hz|||16:9 apsect ratio

8|||240p|||60Hz|||

9|||240p|||60Hz|||16:9 apsect ratio

10|||480i|||60Hz|||pixel quadrupling

11|||480i|||60Hz|||pixel quadrupling, 16:9 aspect ratio

12|||240p|||60Hz|||pixel quadrupling

13|||240p|||60Hz|||pixel quadrupling, 16:9 aspect ratio

14|||480p|||60Hz|||pixel quadrupling

15|||480p|||60Hz|||pixel quadrupling, 16:9 aspect ratio

16|||1080p|||60Hz|||

17|||576p|||50Hz|||

18|||576p|||50Hz|||16:9 aspect ratio

19|||720p|||50Hz|||

20|||1080i|||50Hz|||

21|||576i|||50Hz|||

22|||576i|||50Hz|||16:9 aspect ratio

23|||288p|||50Hz|||

24|||288p|||50Hz|||16:9 aspect ratio

25|||576i|||50Hz|||pixel quadrupling

26|||576i|||50Hz|||pixel quadrupling, 16:9 aspect ratio

27|||288p|||50Hz|||pixel quadrupling

28|||288p|||50Hz|||pixel quadrupling, 16:9 aspect ratio

29|||576p|||50Hz|||pixel doubling

30|||576p|||50Hz|||pixel doubling, 16:9 aspect ratio

31|||1080p|||50Hz|||

32|||1080p|||24Hz|||

33|||1080p|||25Hz|||

34|||1080p|||30Hz|||

35|||480p|||60Hz|||pixel quadrupling

36|||480p|||60Hz|||pixel quadrupling, 16:9 aspect ratio

37|||576p|||50Hz|||pixel quadrupling

38|||576p|||50Hz|||pixel quadrupling, 16:9 aspect ratio

39|||1080i|||50Hz|||reduced blanking

40|||1080i|||100Hz|||

41|||720p|||100Hz|||

42|||576p|||100Hz|||

43|||576p|||100Hz|||16:9 aspect ratio

44|||576i|||100Hz|||

45|||576i|||100Hz|||16:9 aspect ratio

46|||1080i|||120Hz|||

47|||720p|||120Hz|||

48|||480p|||120Hz|||

49|||480p|||120Hz|||16:9 aspect ratio

50|||480i|||120Hz|||

51|||480i|||120Hz|||16:9 aspect ratio

52|||576p|||200Hz|||

53|||576p|||200Hz|||16:9 aspect ratio

54|||576i|||200Hz|||

55|||576i|||200Hz|||16:9 aspect ratio

56|||480p|||240Hz|||

57|||480p|||240Hz|||16:9 aspect ratio

58|||480i|||240Hz|||

59|||480i|||240Hz|||16:9 aspect ratio

DHCP Mode

To set DHCP Mode, make sure DHCP is selected.

Press save, a automatic reboot is expected.

In order to see the network information when in DHCP Mode, select IP/Netmask or Gateway.

STATIC Mode

To set a static IP address, make sure Static is selected, you do not need to save before every field is updated.

A automatic reboot on save, is expected.

The device only supports IPv4

Please make sure the device is connected to the internet.

If there is an available update, you need to confirm before update is started.

The device will boot upon finishing installing

If the device is connected to a network, any computer on the same network can display the timer.

To display the timer browse to: http://<ip>:3000 where IP is the device IP address.

The port:3000 cannot be changed.
